Industrial Jetson Orin AGX System With 10GbE
Key Features:
- 10 Gigabit Ethernet
- -25°C to +70°C Operating Temp
- Wide DC Input
- 2 x Isolated CAN (Inc. CAN FD)
- 5 x GPIO
- Available Until 2032
Overview:
The Aetina AIE-KX13/23 is a fanless Edge AI system powered by the NVIDIA Jetson AGX Orin 64GB, delivering up to 275 TOPS of AI performance. It features a 12-core Arm Cortex-A78AE CPU, 64GB LPDDR5 memory, and 64GB eMMC storage.
Back-Order Lead Time:
Technical Support
- Need Help?
- Talk to a solution specialist we're here to make sure you get your right fit solution.
- +44 (0)1527 512400
- computers@steatite.co.uk
Specifications
- System
Module Compatibility:
NVIDIA Jetson AGX Orin 32GB (AIE-KX13).
NVIDIA Jetson AGX Orin 64GB (AIE-KX23).
AI Performance:
200 TOPS (AIE-KX13).
275 TOPS (AIE-KX23).
GPU:
1792-core NVIDIA Ampere GPU with 56 Tensor Cores (AIE-KX13).
2048-core NVIDIA Ampere GPU with 64 Tensor Cores (AIE-KX23).
CPU:
8-core Arm® Cortex® -A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 (AIE-KX13).
12-core Arm® Cortex® -A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3 (AIE-KX23).
Memory:
32GB 256-bit LPDDR5 204.8 GB/s (AIE-KX13).
64GB 256-bit LPDDR5 204.8 GB/s (AIE-KX23).
Storage:
64GB eMMC 5.1.
Expansion:
1 x M.2 B-Key 3042/3052 (LTE/4G/5G/USB 3.2/USB 2.0).
1 x M.2 E-Key 2230 (WiFi/BT/PCIe/USB 2.0).
1 x M.2 M-Key 2280 (Supports NVMe / PCIe x2 Gen4).
1 x MicroSD Card Slot.
- I/O
Display:
1 x HDMI 2.0 (Type A).
Audio:
Line-out/Line-in/Mic (Optional with daughter board).
Ethernet:
1 x RJ-45 GbE.
1 x RJ-45 (10GbE).
USB:
2 x USB 3.2 (Gen1) (Type A).
1 x USB 2.0 (DB-15).
1 x OTG (Type-C).
1 x USB 3.2 (Gen2) (Type-C).
Other:
2 x I2C.
1 x SPI.
5 x GPIO.
1 x RS-232.
1 x RS-422/485.
2 x CAN 2.0b (Isolation / Supports CAN FD).
1 x MicroSIM Card Slot.
- Power
Input/Connector:
DC-in 9 to 36 VDC / 4-Pin DC Jack Power Connector.
Power Consumption:
9.655 W Idle / 55.25* W Full Loading (AIE-KX13).
9.9 W Idle / 75.25* W Full Loading (AIE-KX23).
*For more test condition information, please refer to user manual.
- Environmental
Vibration:
1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis.
Shock:
10 G, IEC 60068-2-27, half sine, 11 ms duration.
Operating Temperature:
-25°C ~ +70°C.
Storage Temperature:
-40°C ~ +85°C.
Humidity:
95% @ 40°C (104°F) (Non-condensing).
Certification:
CE / FCC Class A.
- Mechanical
Dimension (W x D x H):
210 x 124.7 x 79 mm.
Mounting:
Wall Mount (Optional) / Din Rail (Optional).
Weight (Net):
1969g.
- Other Features
Software Support:
Linux (Support Jetpack 5.0 above).
