Fanless Industrial GPU Computer With 14th Gen Intel Raptor Lake Series CPU
Key Features
- 14th Gen Intel Core CPU Support
- Full-Length PCIe x16 Expansion
- 4 PoE Ports + Dual 2.5GbE LAN
- TPM 2.0 & Wide Voltage Input (12–24V DC)
- Fanless & Rugged Design
- Wide Operating Temperature
Overview
This compact, fanless industrial GPU computer is designed for demanding edge AI and machine vision applications. Powered by 14th Gen Intel® Core™ processors and supporting full-height, full-length PCIe x16 graphics cards, it delivers exceptional performance for real-time data processing, AI inference, and high-resolution imaging.
With rugged construction and wide operating temperature support, it’s built to perform reliably in harsh environments, including AIoT, smart manufacturing, intelligent transportation, and edge analytics deployments.
Pricing Available Upon Request
Need Assistance?
- +44 (0)1527 512 400
Specifications
System
Processor(s):
14th/13th/12th gen Intel® Core™ i9/i7/i5/i3 & Celeron® Processor (35W/65W).
LGA1700 Socket.
Chipset:
Intel® R680E.
Memory:
2 x 262-pin DDR5-4800 SO-DIMM (Up to 64GB).
Storage:
2 x 2.5″ SATA HDD/SSD (Up to 15 mm height) (RAID 0/1 Supported).
1 x NVMe by M.2 Key M 2280.
1 x mSATA (Enable in BIOS setting).
Expansion:
1 x Full-size PCI Express Mini Card Slot (USB 2.0 + PCIe + SIM + mSATA signal).
1 x M.2 Key M 2280 Socket (For storage).
1 x M.2 Key E 2230 Socket (For Wi-Fi 6E).
1 x M.2 Key B 3052 Socket (For 5G).
1 x Internal SIM Slot For PCIe Mini Card slot.
1 x MXM3.1 (Type A) Connector.
1 x Flexible IO Window (2 x DB9 half-cut bracket by default).
I/O
Serial (COM):
2 x RS-232/422/485 (With Autoflow).
2 x RS-232.
USB:
6 x USB 3.2 (Gen2).
Ethernet/PoE:
3 x 2.5 GbE* LAN (Intel® I226-IT).
1 x GbE* LAN (Intel® I219-LM).
*4 x PoE By Option (IEEE802.3at) (Up to 60W).
Display:
2 x HDMI 1.4b (1 x Lockable).
1 x DisplayPort 1.2a.
2 x DisplayPort 1.4a (Via Optional MXM Kit).
Digital I/O:
N/A.
Audio:
1 x Audio (MIC-in/Line-out).
Power
Input Voltage:
9 to 36VDC With Ignition For Standard.
Optional:
PoE Function Only Supports 24V DC Input.
Environmental
Construction:
Aluminum Extrusion & Heavy-Duty Steel (IP40).
Operating Temperature (Without MXM module (For CPU 35W/65W):
-40°C to +65°C (-40°F to +140°F) (With wide temperature DRAM & SSD).
Operating Temperature With MXM module (Only for CPU 35W) (For W.T. MXM T1000 & A500):
-40°C to +50°C (-40°F to +122°F) (With wide temperature DRAM & SSD).
Operating Temperature With MXM module (Only for CPU 35W) (For W.T. MXM A2000 and must with optional fan kit):
-40°C to +50°C (-40°F to +122°F) (With wide temperature DRAM & SSD).
Relative Humidity:
10% – 90% (Non-condensing).
Vibration:
IEC 60068-2-64 (With SSD: 3Grms STD random) (5 – 500 Hz) (1 Hour / axis).
Shock:
IEC 60068-2-27 (With SSD) (50G Half-sine) (11 ms Duration).
Certifications:
CE / FCC Class A / UKCA.
Mechanical
Dimensions (W x D x H):
280 x 210 x 80.5 mm (11.02″ x 8.26″ x 3.16″).
Weight (Net / Gross):
4.2 kg (9.25 lb) / 5 kg (11.02 lb).
Mounting:
Wall / DIN-Rail Kit.
Other Features
BIOS:
AMI.
Watchdog Timer:
255 levels, 1 to 255 sec.
Operating System Support:
Windows 10 / 11 IoT.
Linux.
Others:
TPM 2.0.
1 x Power Button.
1 x Remote Switch.
1 x Front Access SIM Slot With Cover (For M.2 Key B).
1 x Reset Switch Connector.
5 x Antenna Opening.
1 x Grounding Screw.
